※ Complete the coating and granulation of powder.
※ Finish the masking and coloring of powder, granules and pills.
※ Complete the coating of powder to obtain products with high sphericity.
※ Complete the coating liquefaction of powder, which is not easy to agglomerate and adhere.
※ The coating process of finished powder is highly repetitive.
※ Complete the automatic control of powder coating liquid supply, and the temperature in the bed is stable without splash.
※ The coating powder of the powder is automatically sprayed, and the measurement is accurate.
※ The coating of finished powder can handle low-density materials due to the compaction effect of centrifugal force.
※ Complete the coating granulation (pill), coating and drying of powder at one time.
※ The design and manufacture comply with GMP specifications, and the cleaning is fast, complete and free of cross contamination.
Specification items | Inventory(KG/batch) | Rotor speed(rpm) | Rotor diameter(mm) | Motor power of powder supply device(kw) | Fan power(KW) |
360 | 0.5-1.5 | 0-650 | 360 | 0.37 | 1.5 |
750 | 5-15 | 0-250 | 720 | 1.5 | 3 |
1000 | 10-25 | 0-180 | 1000 | 2.2 | 5.5 |
1300 | 15-35 | 0-150 | 1300 | 4 | 7.5 |
